Powerful Bosch Performance CX e-drive with Purion display and integrated, removable 625 Wh battery

120 mm travel with F.O.L.D. kinematics: SR Suntour suspension elements

Fully equipped (EQP): Pannier rack for up to 16 kg, 90 Lux LiteMove lighting system, stand and aluminium mudguards

Bosch CX e-drive & 625 Wh battery

120 mm SR Suntour suspension elements

Pannier rack, 90 Lux light, stand & mudguards

• Brake
  • 203
• Pedal
  • MTB, with reflector
• Frame size
  • S,M,L,XL
  • 40,44,47,50
• Drive train
  • Chain
• Bike stand
  • Ursus rear stand, adjustable, 40 mm mount
• Max total weight
  • 150 kg
• Frame
  • 7005 hydroformed aluminium, 3D forging, 130mm F.O.L.D. kinematic, 148x12 mm through axle, internal cable routing, post mount 180 mm
• Fork
  • SR Suntour XCR 34 Boost 29, LOR, 110x15mm, 120 mm travel
• Handlebar
  • 720 mm, flatbar, backsweep: 9°, 31.8 mm
• Saddle
  • Selle Royal Vivo
• Seat post
  • FOCUS Post Moderne dropper post PM-214, 31.6 mm
• Stem
  • Focus aluminium, 31,8 mm, 60 mm, 17 degree
• Brakes
  • Shimano BR-MT420, 4 piston
• Crank set
  • FSA CK-320, aluminium
• Sprocket
  • Shimano Deore CS-M5100, 11-S, 11-51T
• Transmission
  • front: 34, rear: 11-51
• Wheel rims
  • Rodi TRYP25, with eyelets
• Brake lever
  • Shimano BR-MT420
• Item carrier
  • Massload, 3-leg, 25 kg max. load
• Headlights
  • Litemove SE70, 70 LUX
• Battery
  • Bosch Powertube, 625 Wh, removeable, lockable
  • 625 Wh
• Display
  • Bosch Purion
• Motor
  • Bosch Performance CX Gen4, 75 Nm, 250 W
• Color
  • lightgrey
• Travel
  • 120 mm
  • 130 mm
• Hub
  • Shimano Alivio MT400, 15x110 mm
  • Shimano Alivio MT400, 12x148 mm
• Protective guard
  • aluminium, painted
• Grip
  • Herrmans Click
• Rear derailleur
  • Shimano Deore RD-M5100
• Tire
  • Schwalbe Smart Sam 57-622
• Bottom bracket
  • Integraded in Drive Unit
• Shift/brake lever
  • Shimano BR-MT420
  • Shimano Deore M5100, 11-speed
• Spoke
  • Niro, black
• Chain
  • Shimano CN-HG601
