Frameset
- Seat Binder
- Alloy, 38.6mm
- Frame
- M5 Alloy chassis and rear-end, asymmetrical design, 29/27.5" Trail Geometry with S-Sizing, SWAT™ Door integration, head tube angle adjustment, horst pivot BB adjustment, threaded BB, fully enclosed internal cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 150mm of trave
Suspension
- Rear Shock
- Rock Shox Super Deluxe Ultimate, Rx Trail Tune,RC2T Damper, Hydraulic Bottom Out control , S1:210x50mm, S2-S6:210x55mm
- Fork
- RockShox Lyrik Ultimate, Charger 3 RC2 W/ButterCups, 15x110mm, 44mm offset, S1: 150mm of travel, S2-S6: 160mm of travel
Brakes
- Front Brake
- SRAM Code RS, 4-piston caliper, hydraulic disc, 200mm Centerline
- Rear Brake
- SRAM Code RS, 4-piston caliper, hydraulic disc, 200mm Centerline
Drivetrain
- Bottom Bracket
- SRAM DUB, BSA 73mm, Threaded
- Crankset
- SRAM GX Eagle Alloy, DUB, 165/170/175mm, 32t
- Chain
- SRAM GX Eagle, 12-speed
- Rear Derailleur
- SRAM GX Eagle, 12-speed
- Shift Levers
- SRAM GX, trigger, 12-speed
- Cassette
- Sram XG-1275, 12-speed, 10-52t
- Chainrings
- 32T
Wheels & tires
- Front Tire
- Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3"
- Spokes
- DT Swiss Competition Race
- Rear Tire
- Eliminator, GRID TRAIL casing, GRIPTON® T7 compound, 2Bliss Ready, 27.5 x 2.3"
- Rear Hub
- Roval DT Swiss 370, Ratchet LN, SRAM XD driver body, 12mm thru-axle, 148mm spacing, 28h
- Rims
- Roval Traverse 29F/27.5R Alloy, 30mm inner width, hand-built, 2Bliss Ready
- Front Hub
- Roval, sealed cartridge bearings, 15x110mm spacing, 28h
- Inner Tubes
- Standard, Presta Valve
Cockpit
- Saddle
- Bridge Comp, Hollow Cr-mo rails 155/143
- Grips
- Deity Lockjaw Grips
- Stem
- Deity, 35.0mm
- SeatPost
- OneUp, Dropper Post-V2, MMX lever, 34.9 (S1:120mm, S2/S3:150mm, S4: 180mm, S5/S6: 210mm)
- Handlebars
- Specialized, 6061 alloy, 6-degree upsweep, 8-degree backsweep, 30mm rise, 780mm width
Weight
- Weight
- 15.55kg (34 lb, 4.5 oz)
- Weight Size
- S4
