Product details

A full-power eMTB with a stunningly lightweight body. Meticulously designed and crafted to deliver the ultimate ride.

Powerful Drive, Smooth Assistance

Designed and manufactured by DJI, the Avinox Drive System is seamlessly integrated into Amflow PL, infusing the type of cutting-edge hardware and software that has made DJI an industry leader in drones and camera stabilization technology. The Avinox Drive Unit features a compound planetary gearset with an industry-leading power-to-size ratio.

The durable, high-strength polymer material inside the Drive Unit effectively suppresses noise during high-speed gearbox operation. With multiple precision sensors built-in, combined with advanced DJI algorithms, it provides a strong, smooth assistance for a wide range of scenarios and conditions.

Drive unit features:

Maximum continuous torque: 105 N·m
Drive unit weight: 2.52 kg
Peak power: 850 W

Five Modes, Targeted Assistance

In addition to traditional assistance modes of Eco, Trail and Turbo, the DJI Avinox Drive System also features a specialized Auto mode, which adapts assistance in real-time based on road conditions and riding position. Once enabled, Auto mode empowers users to tackle a wide variety of terrain types and gradients without having to switch modes.

Intelligent Walk Assist, Effortless Control

Amflow PL's Walk Mode features intelligent walk assistance for easy incline traversing, Auto Hold to prevent rollback on slopes, and Hill Start Assist for additional torque to get you started on inclines. It also allows stationary gear shifting for a smooth and intuitive experience.

Versatile Geometry to Dominate Terrain

Amflow PL's frame design features cutting-edge geometry, offering balanced performance that's both lightweight and hyper-agile. This dynamic handling empowers riders to easily take on rugged trails and more technical rides.

29" and 27.5" Compatible

Amflow PL is compatible with both 29 and 27.5-inch rear wheels. By adjusting the flip chips, you can accommodate both sizes without altering the frame's geometric center of gravity. Whether you want to hone your technical skills or simply enjoy high speeds, Amflow PL is ready to ride.

Superior Suspension

The rear shock, co-tuned with FOX, offers sensitive initial stroke response to effectively filter out minor vibrations. It also provides powerful end-stroke support to prevent bottom-outs during continuous high-speed impacts or steep descents, so you can fully enjoy every off-road adventure.

Built-in Display with Smartphone Connectivity

The brain of the DJI Avinox Drive System is the Control Display. This 2-inch full-color OLED touchscreen is integrated directly into the frame. It displays real-time ride data and estimated range, and enables quick changes of the display content with a simple slide.

Anti-Theft Protection

Users can configure multiple anti-theft settings on the Avinox app, including password authentication and abnormal movement alerts. If the bike is moved, an alarm will sound, and the Avinox app will send a push notification, making it convenient for users to check the bike's real-time location and status. Users can also activate a Phone Key to unlock the bike automatically according to proximity.

Geometry

		M	L	XL	XXL
A	Reach	452mm	475mm	500mm	525mm
B	Stack Height	618mm	628mm	641mm	655mm
C	Standover Height	780mm	785mm	790mm	795mm
D	Front Center	782mm	810mm	844mm	873mm
E	Fork Length	570mm	570mm	570mm	570mm
F	Wheelbase	1227mm	1255mm	1289mm	1318mm
G	Chainstay Length	445mm	445mm	445mm	445mm
H	Bottom Bracket Drop	29mm	29mm	29mm	29mm
I	Bottom Bracket Height	345.5mm	345.5mm	345.5mm	345.5mm
J	Effective Top Tube Length	595mm	620mm	648mm	676mm
K	Head Tube Angle	64.5°	64.5°	64.5°	64.5°
L	Head Tube Length	105mm	115mm	130mm	145mm
M	Actual Seat Tube Angle	70°	70°	70°	70°
N	Effective Seat Tube Angle	77°	77°	77°	77°
O	Seat Tube Height	430mm	450mm	470mm	500mm

Amflow PL Carbon (800Wh)

Frame
Amflow PL Carbon Frame
Color: Satin Silver
Rear Travel: 150mm
Wheel Compatibility: 27.5" and 29" Rear Wheels

E-Bike System
Drive Unit: Avinox M1 Drive Unit: 105 N·m
Screen: Avinox 2-inch OLED Control Display
Battery: Avinox Integrated Battery: 800Wh
Controllers: Avinox Wireless Controllers (Right & Left Sides)
Fast Charger: Avinox 12A/508W Fast Charger

Rear Shock
Model: 2026 FOX Float Performance
Shock Type: Trunnion (185×55mm), Custom Tune, EVOL Air Sleeve, 2-Position Lever

Fork
Model: 2026 FOX 36 Performance
Travel: 160mm
Damper: GRIP Damper
Axle: 15×110mm
Rake: 44mm

Transmission
Rear Derailleur: SRAM Eagle 70 Transmission Derailleur
Chainring: SRAM Eagle Transmission E-MTB Chainring 104BCD 34T
Shifters: SRAM Eagle 70 Transmission Shifter | Single Click
Cassette: SRAM XS-1270 Eagle Transmission 10-52T
Chain: SRAM Eagle 70 Transmission Flattop Chain
Crankset: Avinox SL Crank (M/L: 155mm; XL/XXL: 160mm)

Brakes
Brakes: Magura MT5 Hydraulic Disc Brake
Lever: HC Lever
Caliper: 4-Piston
Rotor: 203mm MDR-C (Front & Rear)

Wheels
Rims: Alloy, 29", 30mm Internal Width, 32H, Tubeless Ready
Spokes: SAPIM E-Light J-bend
Front Hub: Alloy, 2 Sealed Cartridge Bearings, 15×110mm Thru-Axle, 32h, 6-Bolt
Rear Hub: Alloy, 4 Sealed Cartridge Bearings, 148×12mm Thru-Axle, 32h, 6-Bolt, 21T

Tires
Front Tire: Maxxis Assegai MaxxTerra 29×2.5" WT 3C EXO E-25 TLR
Rear Tire: Maxxis Dissector MaxxTerra 29×2.4" WT 3C EXO+ E-25 TLR

Handlebar
Model: Amflow Enduro Alloy Handlebar
Rise: 35mm
Width: 800mm
Upsweep: 5 Degrees
Backsweep: 9 Degrees

Saddle
Model: Selle Royal SRX Plus

Seatpost
Model: KS Rage-i
Travel: M: 150mm, L: 170mm, XL/XXL: 190mm

Silver / 800Wh / Medium:

MPN: CP.EB.00000047.01

Barcode: 190021117556

Silver / 800Wh / Large:

MPN: CP.EB.00000046.01

Barcode: 190021117518

Silver / 800Wh / XLarge:

MPN: CP.EB.00000045.01

Barcode: 190021117617

Silver / 800Wh / XXLarge:

MPN: CP.EB.00000044.01

Barcode: 190021117594
